Malham Glass Juliet Balcony

Product Description

The Malham balcony comprises of a 40mm x 40mm hollow steel box section top and bottom rail. The Malham features a central clear 10mm toughened glass panel which makes the best of your view out of your balcony.

The Malham infill bars are made from 12mm x 12mm solid square steel. The two rails that run at the side of the glass panel are 40mm x 8mm steel strips which improve strength.

• If you choose the galvanized option the box section is drilled. This allows the zinc coating to flow through the balcony frame. This results in the balcony being protected from corrosion inside and out.
• Mountings holes are drilled at 10mm. These are designed to suit M8 fixings. The mountings are welded to the outer frame of the balcony. Each mounting foot has three 10mm holes to increase the mounting strength of the balcony.
• The glass panel is held in place with four BZP (Bright Zinc Plated) steel glass mountings. These are fixed to pre-welded tabs on the frame, making installation simple. The balcony is delivered as two separate parts.

The Overall height of the balcony is 1100mm (1.1 Mtr) which meets the current UK building regulations. The gaps between the infill bars are less than 100mm (10 cm) which meets current U.K. building regulations
